KELVINATOR 02 TON SMART-WI-FI INVERTER SPLIT TYPE AC

KELVINATOR 02 TON(KSV-24TPINV-SW)SMART-WI-FI INVERTER SPLIT TYPE AC price in Bangladesh is one of the most sought-after items due to its reliable performance and cost-effective nature. This famous brand offers a wide range of air conditioners. These AC are available in 3-star and 5-star energy ratings, providing customers with great value for money.

Moreover, the latest Kelvinator ACs launched in India and Bangladesh have advanced features such as enhanced cooling capacity and improved compressor efficiency.

Furthermore, it’s important to note that customers should always check the specifications of their chosen model before purchasing to ensure that it meets their needs. All these features make Kelvinator AC price in Bangladesh an excellent choice for anyone looking to buy an air conditioner at an affordable rate.

Model Name : KSV-24TPINV-SW

Type: Cooling only

Control type: Remote

Power supply(Ph-V-Hz):  208-230V~/50Hz/1P

Voltage Range(V): 165~265

Cooling Capacity(Btu/h): 24000(4090~24900)

Cooling Capacity(W): 7035(1200~7300)

Cooling Rated Power Input(W): 2185(300~2800)

Cooling Rated current(A): 10.1(2.5~13.5)

Cooling EER(W/W): 3.22

Cooling Max Power Input(W): 2800

Cooling Max current(A): 13.5

Indoor coil Number of rows: 2

Indoor coil Tube pitch(a)x row pitch(b)(mm): 21×12.7

Indoor coil Fin spacing (mm): 1.4

Indoor coil Tube outside dia. and type (mm): Φ7, inner groove

Indoor coil Number of circuits (mm): 4 in 4 out

Outdoor coil Number of rows: 2

Outdoor coil Tube pitch(a)x row pitch(b)(mm): 19.5×11.6

Outdoor coil Fin spacing(mm): 1.2

Outdoor coil Tube outside dia. and type(mm): Φ5, inner groove

Outdoor coil Number of circuits: 3 in 3 out

Indoor unit Dimension(W*D*H)(mm): 1010×315×220

Indoor unit Packing   (W*D*H)(mm): 1096×390×297

Indoor unit Net/Gross weight(kg): 13/16

Outdoor unit Dimension(W*D*H)(mm): 853×349×602

Outdoor unit Packing  (W*D*H)(mm): 890×385×628

Outdoor unit Net/Gross weight(kg): 30/35

Refrigerant piping Liquid side/ Gas Side(mm(inch): φ6(1/4")/φ12(1/2")

Refrigerant piping Max. refrigerant pipe length(m): 15

Refrigerant piping Max. difference in level(m): 5

Pressure High(DP)(MPa): 4.5

Pressure Low(SP)(MPa): 1.9

Refrigerant: R410A/990g

Ambient temperature(℃): -15~50

Suitable area(m2): 30~50

Power supply cord: 3×1.5mm²
