Model Name | RSDC-18RTSI |
Type | Cooling only |
Control type | Remote |
Power supply | Ph-V-Hz | 1Ph-220-240V~50Hz |
Voltage Range | V | 165~265 |
Cooling | Capacity | Btu/h | 18000(3412~19107) |
W | 5275(1000~5600) |
Rated power input | 1735(300~2000) |
Rated current | A | 8.0(1.4~10) |
EER | W/W | 3.04 |
Max power input | W | 2000 |
Max current | A | 10 |
Indoor coil | Number of rows | | 2 |
Tube pitch(a)x row pitch(b) | mm | 21x12.7 |
Fin spacing | 1.4 |
Tube outside dia. and type | Φ7, inner groove |
Coil length x height x width | |
Number of circuits | | 3 in 3 out |
Outdoor coil | Number of rows | | 1 |
Tube pitch(a)x row pitch(b) | mm | 21x18.2 |
Fin spacing | 1.3 |
Tube outside dia. and type | Φ7, inner groove |
Coil length x height x width | |
Number of circuits | | 1 in 1 out |
Indoor unit | Dimension(W*D*H) | mm | 910×294×206 |
Packing (W*D*H) | 979×372×292 |
Net/Gross weight | Kg | 9/12 |
Outdoor unit | Dimension(W*D*H) | mm | 795×305×549 |
Packing (W*D*H) | 818×325×520 |
Net/Gross weight | Kg | 25/30(with pipe) |
Pressure | High(DP) | MPa | 4.5 |
Low(SP) | 1.9 |
Refrigerant | | R410A/0.78 |
Ambient temperature | ℃ | 18~50 |
Suitable area | m2 | 20~35 |
Connecting Wiring | Size x Core number | 4×1.5 |
Power supply cord | 1.5mm² |
Qty 40'HQ | 232 |
Installation charge will be TK 3500
Installation Charges are not Included. The cost & works for electric wiring, civil position, and Angle, extra pipe charge should be borne by the customer.
